Dahua PFM922I-6UN-C CAT6 UTP CCA Network Cable 305M

Short Description: A 305-metre CAT6 UTP cable with CCA conductors, HDPE insulation and a PVC outer sheath. It is a bulk-cabling option for projects that specifically accept copper-clad aluminium cable.

Features & Technical Specifications

Full Description

CCA Conductor Material

This model uses copper-clad aluminium rather than oxygen-free copper. Match the conductor specification to the project requirements instead of treating similarly named Dahua cables as interchangeable.

23 AWG and HDPE Insulation

Dahua specifies 23 AWG conductors with a nominal 0.57 mm diameter. The insulation is HDPE, with a stated 1.02 mm diameter and minimum thickness of 0.21 mm.

PVC Outer Sheath

The cable uses a PVC exterior with the stated CPR Eca flame classification. Select connectors that accommodate the cable construction and conductor dimensions, then test completed links as part of installation.

Project Length and Termination

The 305 m length is the total supplied cable, not a guaranteed distance for one Ethernet connection. Plan individual runs to the requirements of the network and use compatible termination hardware.

Ideal Applications

• Custom-length LAN cable runs
• Home or office projects specifying CCA cable
• Structured cabling with compatible termination hardware

Why Choose Dahua PFM922I-6UN-C?

• Clearly identified CCA conductors
• 23 AWG conductor size
• 305 m carton for custom cable runs
• HDPE insulation and PVC sheath

Shop Dahua PFM922I-6UN-C in Jordan

Explore this 305 m CAT6 cable at SAMMANPC - AlSamman For Computer. Compare its construction and specifications for your project in Amman, Irbid or elsewhere in Jordan.

Review the listed price and browse the SAMMANPC network cables collection to choose the appropriate cable.
